  • AMD Fenghuang 15FF Graphics Chip Equipped APU Shows Up on 3DMark !!!

    AMD Fenghuang 15FF Graphics Chip Equipped APU Shows Up on 3DMark ? Faster Than RX Vega M GH, 2 GB HBM2 Clocked at 1200 MHz




    AMD is working on a lot of internal projects that have yet to see the light of day, one such project is the Fenghuang 15FF graphics chip for accelerated processing units. The Fenghuang 15FF APU was spotted last year in an entry within SiSoftware Sandra database but since then, no other info made its way on the web until today.
    AMD?s Fenghuang APU Spotted in 3DMark ? Faster Than Intel?s Kaby Lake-G Vega Graphics, 2 GB HBM2 Onboard

    The AMD Fenghuang 15FF is an internal codename for the graphics while the chip it was tested with is currently codenamed DG02SRTBP4MFA. There have been different codenames spotted since the chip first leaked out but it should be clear that this is very much an early sample at this stage.




    Looking at the specifications reported in 3DMark, the processor itself seems to be a Zen+ based APU part with 4 cores and 8 threads. The chip is clocked at 3.00 GHz base frequency while turbo frequency is currently not reported correctly. The graphics side features 2 GB of HBM2 memory which is clocked at 1200 MHz (2.4 GHz effective). This may just be the fastest clocked HBM2 VRAM speeds that AMD has featured on their graphics yet. The core clock for the chip is reported at 300 MHz but that must be idle as the benchmark isn?t reporting boost/turbo clocks correctly at the moment.
    We have previously known that the chip features 28 CUs which incorporate 1792 SPs, making it the beefiest APU solution to date. The AMD supplied Kaby Lake-G chips with RX Vega GPUs come with 24 CUs which has 1536 cores and 4 GB of HBM2 at 945 MHz in comparison.
    AMD Fenghuang APU Specs Comparison

    Graphics Version AMD Radeon RX Vega Graphics AMD Radeon RX Vega M GH Graphics AMD Radeon RX Vega M GL Graphics
    GPU Architecture Vega Vega Vega
    Process Node 14nm FinFET 14nm FinFET 14nm FinFET
    Compute Units 28 CUs 24 CUs 20 CUs
    Stream Processors 1792 SPs 1536 SPs 1280 SPs
    TMUs / ROPs 112 / 64 96 / 64 80 / 32
    Base Clock TBD 1063 MHz 931 MHz
    Boost Clock TBD 1190 MHz 1011 MHz
    FP32 Performance (Boost Clock) TBD 3.7 TFLOPs 2.6 TFLOPs
    VRAM 2 GB HBM2 4 GB HBM2 4 GB HBM2
    Memory Bus 1024-bit 1024-bit 1024-bit
    Memory Clock 2.4 Gbps 1.6 Gbps 1.4 Gbps
    Memory Bandwidth 307.2 GB/s 204.8 GB/s 179.2 GB/s


    The chip has in fact been compared to the Intel Core i7-8809G processor which features the RX Vega M GH graphics and is the fastest solution supplied to Intel by AMD. In the GPU benchmark tests, the AMD Fenghuang chip absolutely demolishes the Intel + Vega processor and only lacks behind in the Physics test which is a CPU intensive benchmark. Overall, if AMD can manage to bring such a chip on to the desktop front, it can be a great solution for discrete GPU less gaming. AMD is hosting their Computex 2018 press conference next week where they will be showing off never-before-seen hardware demonstrations so maybe we can expect a look at Fenghuang based APUs.



    -----------------------------------------------------------------------



    -----------------------------------------------------------------------

    https://wccftech.com/amd-fenghuang-apu-3dmark-specs-performance-leak/
    Last edited by 111111; 2 Jun 2018, 19:57:57.

  • #2
    1x6

    Comment


    • #3
      ถ้ารุ่นนี้ใส่ใน Ryzen 7 APU AM4 จะแจ่มน่าดูเลยครับ
